Moonstone Motherboards

Moonstone R9 Board

CBM3r9MSB
  • AMD® Ryzen™ 9-7940HS
  • Cores 8, Threads 16
  • AMD® Radeon™ 780M
  • Passmark Coming Soon...

Now Shipping

Product Build Options

Memory (RAM)*

This unit comes with 8GB DDR5 Memory. Upgrade now and increase your memory as high as 96GB at a discounted price.

M.2 Gen4 Storage Option*

This unit comes pre-installed with a 256GB Gen4 PCIe M.2 SSD primary storage device. Upgrade for more SSD storage at a discounted price.
*See our legal page for our SSD size classification.

Operating System*

This is the operating system that will be installed to the primary storage device. Simply NUC will install the OS to the storage device with the highest performance. Contact Sales if you want your OS installed to a specific storage device or if you do not see your desired OS on this list.

AX211 Optional vPro Wifi option*

Select the Intel AX211 vPro if the vPro option is selected for the current unit. Otherwise select the regular Intel AX211.

Power Supply*

We can ship this unit with a compatible power supply if you do not already have one.

Extended Support Service*

This unit comes with 3 FREE years of Simply NUC support service, which includes part and labor support as well as outbound shipping. Optionally, this coverage can be extended to 5 years.

HDMI Port Accessories

Here is a list of available accessories that connect to an HDMI port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

Second HDMI Port Accessories

Here is a list of available accessories that connect to an HDMI port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

USB Type-C Port Accessories

Here is a list of available accessories that connect to a USB Type-C port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

USB 3.2 Port Accessories

Here is a list of available accessories that connect to a USB 3.2 port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

Mouse and Keyboard Pack

These are USB mouse and keyboard combo packages.

USB OS Restore Key

This is a USB storage device with a copy of the installation of the OS chosen for this model.

Review Your NUC

Moonstone Motherboards

Moonstone R9 Board

Volume Quote
CBM3r9MSB Moonstone R9 Board

Base CPU Frequency

4.0GHz

Turbo Boost

5.2GHz Boost

Cores & Threads

Cores 8, Threads 16

Graphics

AMD® Radeon™ 780M

Max Memory

64GB

Networking

1x Intel 2.5Gb LAN

Max Resolution

7680 × 4320

Video Output

2x HDMI 2.1 TDMS, 2x DP 2.0 via USB-C (Alt-DP)

I/O

2x USB 4 Type-C, 3x USB 3.2 Gen2 Type-A, 1x USB 2.0 Type-A, 1x 3.5mm stereo headset jack

The New Standard of Innovation-Driven Performance

Moonstone is a 4×4 motherboard packed with features, from its AMD Ryzen™ 7940HS processor to its RDNA2-based Radeon™ 780M Graphics, whether you are working, gaming or relaxing, Moonstone will give you top-tier performance, all day long. Moonstone supports up to 96GB of DDR5-5600 high-speed RAM and up to 16TB of storage, helping you increase your computing output while keeping a minimal footprint on both your desk and your energy bill. AMD’s new 7940HS processor with Simply NUC’s new Dual Exhaust Cooling solution will keep your Moonstone motherboard at its maximum potential with minimal thermals, no matter the task.

Enhanced I/O and Crystal Clear Graphics

Moonstone harnesses the Radeon™ 780M graphics to give you the best visual experience possible from a small form factor motherboard, with features like DirectX® 12 Ultimate allowing things like ray tracing and AMD FidelityFX, an open-source image quality toolkit, both to expand and enhance both your graphics-heavy workloads and gaming experiences. Moonstone also features dual HDMI 2.1 ports and dual USB-C with Alt-DP ports, allowing crystal clear graphics on up to four 4K displays or a single 8K display to get the most out of your system. Connect all your peripherals to your Moonstone system with its four USB-A ports, 2.5Gb LAN port and dual USB-C ports.

Launching your PC Performance to the Moon

AMD’s Zen3+ architecture offers you 8 cores with 16 threads of computing power, without drawing too much energy thanks to the new from the ground up power management redesign, allowing Moonstone to put unused cores to sleep to prevent excess power draw. These cores can then be booted back up within a millisecond, allowing an uninterrupted experience while keeping your energy costs down. Upgrade your compute power today and enjoy earth-shattering results, with Moonstone.

  1. AMD® Ryzen™ 9-7940HS CPU
  2. AMD® Radeon™ 780M
  3. 2x DDR5-4800 SO-DIMM, 64GB max
  4. 1x M.2 22×80 M-key supporting x4 PCIe Gen4 or SATA SSDs
  5. 1x 3.5mm stereo headset jack
  6. 1x Front USB 3.2 Gen2 Type-A
  7. 1x Front USB 2.0 Type-A
  8. 2x HDMI 2.1
  9. 2x Rear USB 4 Type-C (Alt-DP)
  10. 2x Rear USB 3.2 Gen2 Type-A
  11. 1x Intel 2.5Gb LAN
  12. 1x 19VDC, 120W Power Supply
