2x HDMI 2.0a with built-in CEC for all ports; 4-lane eDP
1x front USB 3.1 gen 2 type A ports, 2x rear USB 3.1 gen 2 type A ports, 1x front port, 2x backpanel USB 2.0 ports
Intel® NUC Elements are an entirely new way to design and build embedded solutions and Mini PCs. Compute module options along with a series of Intel-designed components, deliver the flexibility of modular computing letting you create the exact systems you want. Intel NUC Elements include compute module and chassis module options, allowing you to develop innovative solutions. Start with a compute module with the exact processor you need and plug it into your choice of chassis module. By transforming how systems can be built and serviced, Intel is once again revolutionizing computing in order to help you succeed. From embedded deployments to rugged systems in unique environments, to full systems in a business or vertical environment, the Intel NUC Elements let you deliver custom solutions with minimal R&D time.
Intel® NUC 8 Rugged is a modular PC kit that’s small in size but not on toughness or reliability. It features a fanless, ventless design to minimize particle intrusion, so it’s built to survive environments most PCs can’t – from a busy factory floor to a dusty warehouse. And even without a fan, it can operate in temperatures from 0-40˚C to thrive in severe in-the-field conditions. And with the compute modules, systems are scalable from Celeron all the way up to Core i7 with vPro.
BUILD EMBEDDED SOLUTIONS
Housed in a small, quiet, fanless chassis that’s slim enough to fit almost anywhere, the NUC 8 Rugged can be easily integrated into digital solutions. The two chassis options provide flexibility in usage, and are qualified for 24/7 operation, making it the ideal PC solution to keep edge analytics, digital signage, or surveillance cameras up and running around the clock. All modules carry a 3-year warranty, for performance that’s designed to last.
11th Generation Intel® Core™ i3-1115G4
Intel® UHD Graphics
8GB LPDDR4X RAM
M.2 2280 key M and 22×42/80 key M slot for PCIe x4 Gen3 NVMe / AHCI or SATA3 SSD
1x internal USB 3.0 header
2x RS232 serial port headers
Kensington Lock with Base Security
1x front USB 3.1 gen 2 type A port
12 – 24V DC rear jack, internal 2×2 power connector (12 -24V
