Raptor Canyon

Intel® NUC 13 Extreme

NUC13RNGi9 Full
  • Intel® Core™ i9-13900K
  • Cores 24, Threads 32
  • PCIe x16 Gen5 triple-wide socket
  • Passmark Coming Soon...

Please contact sales if you would like to purchase this unit

Contact Sales

NUCNUC13RNGi9 Intel® NUC 13 Extreme

Base CPU Frequency

2.2 GHz

Turbo Boost

5.8 GHz

Cores & Threads

Cores 24, Threads 32

Graphics

PCIe x16 Gen5 triple-wide socket

Max Memory

64GB

Networking

1x Marvell 10GbE LAN, 1x Intel 2.5Gb LAN, Intel® Killer™ Wi-Fi 6E AX1690i w/ 6GHz + Bluetooth® v5.2

Max Resolution

7680 x 4320

Video Output

1x HDMI 2.1TMDS compatible port, 2x Thunderbolt 4 (DP 1.4)

I/O

2x Thunderbolt 4 ports, 6x USB 3.2 Gen2 Type-A ports, 1x SDXC slot, 2x USB 3.2 Gen1 Type-A 1x USB 3.2 Gen2 Type-C

Revolutionize your Gaming and Workstation Experience

Unlock a new age of gaming potential, with Raptor Canyon, the new Intel® NUC 13 Extreme. Powered by Intel’s hot-off-the-press 13th Gen i9-13900K 125W desktop processor in a whole-new 14L form factor, Raptor Canyon allows for increased cooling, expanded customizability, and heightened functionality. For the first time on an Intel NUC, you can customize your Raptor with up to 64GB of DDR5-4800+ memory and up to 40TB of storage, opening the doors to playing all your favorite AAA games at the highest settings, flawlessly. The Intel® NUC 13 Extreme is here to revolutionize your gaming and workstation experience.

Peak Performance with Raptor Canyon

Raptor Canyon is the highest performing NUC on the market, bringing with it the ability to harness new technologies, such as DDR5 RAM, with speeds up to 5600MHz and three Gen4 compatible M.2 sockets to help you compete at the top of the leaderboard, or effortlessly tackle with your most complex CAD or content creation tasks. With Raptor Canyon, there is nothing to hold you back from peak PC performance. Its Gen5 PCIe x16 socket gives you the flexible functionality you need, supplying up to 450W for your new triple-slot 12” graphics card or I/O expansion card of your choice. Raptor’s new modern design with optimal airflow will minimize noise and throttling under intense workloads, and its beefy 750W internal power supply ensures you the peak performance you need to take your gameplay to the next level.

Mini. Modular. Mind-blowing.

Raptor Canyon offers heightened functionality with an upgraded offering of I/O, from its dual-LAN ports with 10Gb and 2.5Gb speeds for a super-fast reliable connection, to its dual Thunderbolt 4 ports for extra monitors, or I/O hubs to keep you at the height of productivity and performance. Raptor Canyon introduces a new NUC form factor – the larger chassis opens up expanded customizability with additional space to mount extra drives and connect more peripherals than ever before, helping you drive efficiency while still maintaining a significantly smaller footprint than a full-sized tower PC. Join the new era of gaming, with Raptor Canyon, it’s Mini, Modular, and Mind-blowing.

  1. Intel® Core™ i9-13900K
  2. Intel® UHD Graphics 770
  3. Dual channel DDR5-4800 SODIMMs, max 64GB
  4. 1x M.2 22×80 for NVMe
  5. 2x M.2 22×80 for NVMe or SATA SSD
  6. Intel® Killer Wi-Fi 6E AX1690i  w/ 6GHz + Bluetooth® v5.2
  7. Auxiliary Extension x4
  8. 4 addressable RGB headers
  9. 2x 120mm System Fans
  10. 2x USB 3.2 Gen 1 Type-A (top)
  11. 1x USB 3.2 Gen2x2 Type-C (top)
  12. 1x 3.5mm stereo headphone jack (top)
  13. 2x external antennas
  14. 6x rear USB 3.2 Gen 2 ports
  15. 10 Gb Ethernet (AQC113) port
  16. Intel® 2.5 Gb Ethernet (i226-V) port
  17. 2x Thunderbolt 4 / USB4 Type-C ports
  18. 750W 80+ Gold SFX 12VO internal power supply
  19. 1x HDMI 2.1 TMDS compatible connector (up to 4k60)
  20. Analog audio
  21. Triple slot PCIe X16 Gen5 socket
  22. Kensington lock
