Onyx

Onyx v9

NUC13OXKv9
  • Intel® Core™ i9-13900H
  • Cores 14, Threads 20
  • Intel® Iris® Xe Graphics
  • Passmark Coming Soon...

Now Shipping

Product Build Options

AMT Configuration Option

To fully utilize the vPro enabled chipset on this device to its potential, SprinxleIQ with remote manageability or AMT will need to be configured. If you would like us to configure SprinxleIQ or AMT, we can do that for you.

Memory (RAM)*

This unit comes with 8GB DDR5 Memory. Upgrade now and increase your memory as high as 64GB at a discounted price.

M.2 Gen4 Storage Option*

This unit comes pre-installed with a 256GB Gen4 PCIe M.2 SSD primary storage device. Upgrade for more SSD storage at a discounted price.
*See our legal page for our SSD size classification.

Operating System*

This is the operating system that will be installed to the primary storage device. Simply NUC will install the OS to the storage device with the highest performance. Contact Sales if you want your OS installed to a specific storage device or if you do not see your desired OS on this list.

NUC Lid Options

These are lid replacements for your NUC unit. Limited availability until May.

Extended Support Service*

This unit comes with 3 FREE years of Simply NUC support service, which includes part and labor support as well as outbound shipping. Optionally, this coverage can be extended to 5 years.

HDMI Port Accessories

Here is a list of available accessories that connect to an HDMI port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

Second HDMI Port Accessories

Here is a list of available accessories that connect to an HDMI port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

USB Type-C Port Accessories

Here is a list of available accessories that connect to a USB Type-C port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

USB 3.2 Port Accessories

Here is a list of available accessories that connect to a USB 3.2 port. Need multiple accessories for your unit? Check out the NUC Accessories under the Products menu!

Chassis Mount

These mounts are durable, high quality metal frames and can be used to keep your NUC out of the way while also preventing the NUC from being removed from its mount by mistake.

Mouse and Keyboard Pack

These are USB mouse and keyboard combo packages.

USB OS Restore Key

This is a USB storage device with a copy of the installation of the OS chosen for this model.

Review Your NUC

Onyx

Onyx v9

Volume Quote
NUC13OXKv9 Onyx v9

Base CPU Frequency

Turbo Boost

5.4GHz Turbo

Cores & Threads

Cores 14, Threads 20

Graphics

Intel® Iris® Xe Graphics

Max Memory

96GB

Networking

Intel® Wi-Fi 6E AX210 + Bluetooth 5.2, 1x 2.5Gb LAN

Max Resolution

7680 × 4320

Video Output

2x HDMI 2.1 TDMS, 2x DP 2.0 via USB-C (Alt-DP)

I/O

2x USB 4.0 Type-C, 3x USB 3.2 Type-A, 1x USB 2.0 Type-A, 1x 3.5mm stereo headset jack, 1x MicroSD card slot

Unmatched Performance for Modern Business

Onyx is the latest and greatest in ultra-small form factor compute power from Simply NUC, driving unmatched performance for modern business from the desk to the edge to the cloud and back. Powered by Intel’s 13th Gen Raptor Lake 13900H processor and kept cool with Simply NUC’s Dual Exhaust Cooling solution, the Onyx NUC features a Core i9 option on the high-end, a new performance level never achieved before in a 4×4 chassis. With support for up to 64GB of DDR5-5200 memory, up to 16TB of storage, and off-the-charts benchmark results, Onyx delivers all the power, without the tower.

Onyx – Defined by You, Built for You

Onyx may be a Simply NUC product, but it was defined by our customers, and built to meet your needs, with key features like dual HDMI 2.1, dual USB 4.0 Type-C, and a 2.5Gb Ethernet port to name a few. The Onyx NUC gives you the ability to expand its feature set to match your specific usage needs, with a rear I/O expansion panel on the full height chassis and a replaceable lid, giving you a plethora of additional I/O options such as USB, HDMI, LAN, or serial ports. From office workstations, to on-prem heavy edge computing, to robotics and sophisticated IoT networks, Onyx v9 has the flexibility and performance options to perfectly serve your usage requirements.

Performance with Uncompromised Security and Reliability

Powered by Intel’s 13th Gen Raptor Lake 13900H processor, featuring 14 cores and 20 threads, Onyx packs outsized performance into a small chassis. Raptor Lake processors feature Intel Thread Director, using machine learning to schedule tasks on the right core at the right time, preventing background tasks from slowing you down, and keeping the focus on the primary workload. Select Onyx SKUs also feature Intel vPro technology allowing for remote management of your 24×7 tested computer fleet and secure communications across networks. Upgrade to Onyx v9 today, and enjoy uncompromised and highly reliable processing power.

  1. Intel® Core™ i9-13900H
  2. Intel® Iris® Xe Graphics
  3. 2x DDR5-5200 SO-DIMM, 96GB max
  4. 1x M.2 22×80 M-key supporting x4 PCIe Gen4 or SATA SSDs
  5. Intel® Wi-Fi 6E AX210 + Bluetooth 5.2
  6. 1x Front USB 2.0 Type-A
  7. 1x Front USB 3.2 Gen2 Type-A
  8. 1x 3.5mm stereo headset jack
  9. 1x Kensington lock
  10. 1x 19VDC, 120W Power Supply
  11. 2x Rear USB 4.0 Type-C (Alt-DP)
  12. 2x HDMI 2.1 TDMS
  13. 1x Intel 2.5Gb LAN
  14. 2x Rear USB 3.2 Gen2 Type-A
  15. 1x MicroSD card slot
